Utensil and Pot Washer 500 x 600 mm

Utensil and Pot Washer 500 x 600 mm

• Realisation "double walled".
• Loading height for trays 380 mm (plates diam. 380 mm).
• LMD mixed washing, also dishes, cutlery
• Standard rinsing pump (atmospheric boiler)
• Made of double walls made of stainless steel AISI 304.
• Cycles 60'' - 120"-80" or continuous.
• Rotating washing and rinsing arms (upper and lower) (stainless steel lower).
• Self cleaning sprinklers.
• Tank (23Lit. 2,1Kw) with rounded edges, "deep-drawn" bottom.
• "Integral" tank filter, made of "cast" stainless steel.
• Adjustable stainless steel feet (125-190 mm).
• Removable control panel, facilitating after-sales service.
• Pump increasing the water pressure of the network.
• Automatic filling of the tank.
• High efficiency, energy-saving washing pump (double flow) with soft start device.
• Check valve.
• Hot water rinsing (water consumption per cycle 2.5 litres), insulated stainless steel boiler (7 Lit., 6kW).
• Possibility of regulating the temperature of the tank and boiler.
• Micro switch, when the door opens.
• Safety thermostat.
• Standard : 1 generic basket, stainless steel support for 5 dishes.

PLUS:

• Peristaltic" dispenser for rinsing product supplied as standard.
• Peristaltic" dispenser for liquid detergent supplied as standard.
• CSD digital control panel (soft touch).
• EED energy saving.
• DRD accelerated preheating phase.
• DID automatic diagnostic in case of problems.
• ADD display of boiler and tank temperature (HACCP conform)
• Double-walled door, "soft contact" opening.
• RGD Diamond Exclusivity, ensures rinsing at a constant temperature of 80°C, as well as a stable pressure throughout the rinsing process.
• BTD "Break Tank" anti-pollution device, AB type.
• NB: machines guaranteed for "osmosis" water supply.
• BREAK TANK : The "break tank" is an AB type "anti-pollution" device (UK standards) 1) It prevents the tank water (with detergents) to flow back into the distribution system 2) Its pump guarantees a constant pressure during the whole rinsing, the drying and hygiene are guaranteed by a T° of 85°C... until the last drop of water!
